BEDE Dust Cover 5 6 7 Pin Circular Connectors 5A 500V WS16

WS16 Circular Connector With Dust Cover Panel Mounting Connectors 5 6 7 Pins 5A 500V

Product Description

1. WS16 circular connector kits, buy only the female connector or male connector are available
2. Dust cover and cable cover material is PVC soft plastic, dustproof and moistureproof,
3. Main body material is zinc alloy with chrome plated
4. The insulator material is PPS plastic, the insulation resistance is greater than 2000MΩ
5. Material of contact pins is brass, has good electrical conductivity, in order to reduce the contact resistance, it also has a gold-plated surface treatment
6. Pins: 5  6 7

Product Size

Wiring end:   ΦD=21   L=44.8mm   Φd max=10mm

 Panel mounting end:    d=M16   D=M18  C_max= 5mm L= 9.7mm   L1=26 mm   L2= 22mm   B= 21mm

Mounting hole:    Φd=16mm   h=15.4mm

Notice

  Our default that the wiring end is male connector and panel mounting end is the female connector, as shown in the following figure A type, if B type is required, please contact us in advance

Electrical data

Similar product

This page is about WS16, WS20, WS24, WS28 on sales also, the series also includes wire docking mode, square flange mode, please feel free to contact us if you are interested
